Using a mere 40W of power, the Image Spot LED projector provides an amazing amount of light output from a versatile and compact design. The fixture’s crystal clear optics ensure bright imaging in virtually any environment, and enable vivid gobo projection up to 40 feet (12m) away!
Image Spot’s IP65-rating allows it to be used both indoors and outdoors. An Image Spot HT (High Temperature) model is available for installations in environments with high ambient temperatures.
Please note that the Image Spot does not ship with a lens. Choose from the available very narrow, narrow, medium and wide Lens Optic Accessories when ordering to achieve the imaging or beam spread your project requires.
Use the Image Spot to project any Rosco pattern – from the world’s largest library of standard gobo designs – or, project a custom gobo with a specific image, logo or message. The Image Spot is ready to accept steel, black and white & color glass gobos, and even thicker Effects Glass gobos such as Image Glass and ColorWaves. The Image Spot gobo cassette also accepts Rosco Permacolor dichroic glass filters for long term color effects, correction or enhancement.
Image Spot's engineered optics produce a light beam with the highest uniformity and resolution, which enables the fixture to project even illumination or a crisp gobo image at distances up to 40 feet (12m).
The Image Spot’ IP65 rating offers the versatility to create spot-lighting or project gobos everywhere those effects may be required, both indoors and outdoors. An Image Spot HT model is also available for installations into areas with high ambient temperatures.
The Image Spot uses a single channel to control the dimming of the LED. Choose from multiple control options including 0-10V, push-to-dim, DALI or DMX/RDM. The fixture includes a factory installed exterior-rated hybrid cable for wiring both power and data in a clean cable management form.
What’s In The Box:
Please note that the Image Spot does not ship with a lens. Make sure to choose an Image Spot Lens Optic Accessory when ordering to achieve the beam spread your project requires. Lens options include: 10°, 19°, 25° and 30°. Click on Photometrics tab above or download the Image Spot Photometrics Data Sheet for more information.
Input Voltage: 100-277VAC
Power Consumption: 40 Watts at maximum output
Color Temperature Options: 5500K or 3000K or UV
CRI:
Output:
Lumen Maintenance: 50,000 hours at 45°C (LM-79-08)
Power Connection: 6.5 ft (2m) hybrid data/mains cable (IP65) (Connectors not included.)
Data: DMX/RDM, 0-10V, DALI, Push DIM Options
DMX Addressing: RDM functionality available for addressing
Image Spot Dimensions
Dimensions:
Weight:
Operating Temperature:
Humidity: 0 - 95% non-condensing
Housing: Anodized Aluminum Extrusion
Approvals:
Image Spot Gobos & Permacolor Filters:
For optimum image quality and performance, use Rosco Image Spot Gobos and Permacolor Filters, which feature custom bezels that enable a secure fit inside the Image Spot gobo cassette.
XXXXX-SPOT Image Spot Standard Gobo, XXXXX = The five digit standard gobo number
2507210ISPOT Image Spot Custom Steel Gobo
260CUSBWOSPO Image Spot Custom B&W Glass Gobo
260CUS1COSPO Image Spot Custom One-Color Glass Gobo
260CUS2COSPO Image Spot Custom Two-Color Glass Gobo
260CUSMCOSPO Image Spot Custom Multi-Color Glass Gobo
1203-XXXX-SPOT Image Spot Permacolor Dichroic Glass Filter, XXXX = the four digit color number (includes bezel to fit inside gobo cassette)
Product Numbers
296 00004 0651 - Image Spot 5500K - IP65 - w/o Lens - Black
296 00004 0652 - Image Spot 5500K - IP65 - w/o Lens - White
296 00004 0653 - Image Spot 5500K - IP65 - w/o Lens - Silver
296 00004 1651 - Image Spot 5500K - IP65 w/DMX - w/o Lens - Black
296 00004 1652 - Image Spot 5500K - IP65 w/DMX - w/o Lens - White
296 00004 1653 - Image Spot 5500K - IP65 w/DMX - w/o Lens - Silver
296 00006 1654 - Image Spot HT 5500K - IP65 w/DMX - w/o Lens - Black
296 00006 1655 - Image Spot HT 5500K - IP65 w/DMX - w/o Lens - White
296 00006 1656 - Image Spot HT 5500K - IP65 w/DMX - w/o Lens - Silver
296 00003 0651 - Image Spot 3000K - IP65 - w/o Lens - Black
296 00003 0652 - Image Spot 3000K - IP65 - w/o Lens - White
296 00003 0653 - Image Spot 3000K - IP65 - w/o Lens - Silver
296 00003 1651 - Image Spot 3000K - IP65 w/DMX - w/o Lens - Black
296 00003 1652 - Image Spot 3000K - IP65 w/DMX - w/o Lens - White
296 00003 1653 - Image Spot 3000K - IP65 w/DMX - w/o Lens - Silver
296 00006 1651 - Image Spot HT 3000K - IP65 w/DMX - w/o Lens - Black
296 00006 1652 - Image Spot HT 3000K - IP65 w/DMX - w/o Lens - White
296 00006 1653 - Image Spot HT 3000K - IP65 w/DMX - w/o Lens - Silver
Rosco Image Spot® Photometrics Calculator
Image Spot Video
Rosco Image Spot® DWG File
Rosco Image Spot® HT DWG File
Case Study: Gobo Projections Enliven Historic Parks In Bad Elster
Case Study: 3 Ways To Use Rosco Image Spot® For Intricate Gobo Projections
Case Study: A Norwegian Town Tells Its Story With “Picture Poem” Gobo Projections
Case Study: Using Gobo Projections To Create Vivid Images On Building Façades
Case Study: Creating Ambience With Gobo Projections For Park Lighting
Case Study: Rosco Image Spots® Illuminate Poetic Gobo Projections at Château de Bonaguil
Case Study: Bringing Faded “Ghost Signs” Back Into The Spotlight
Case Study: Gobo Projections Create A Luminous, Spiritual Journey Inside Metz Cathedral
Case Study: Re-creating Passageways Of The Past With Gobo Projections
Case Study: Using Gobo Projections To Enliven Dark Walkways
Case Study: A Fusion Of Ancient Tradition And Lighting Technology At Nagoya Castle
Case Study: Dallas Landmark
Case Study: Artequin Museum
Case Study: Legends of Tomorrow
Case Study: Image Spot® Shines A Light On Organ & Tissue Donation
Case Study: Experiencing Westminster Bridge Road In A Whole New Light
Case Study: Highlighting The Architectural Details Of A Gothic Façade With Rosco Image Spots®
Case Study: Gobo Projections + Augmented Reality Highlight The History Of Vitré, France
Image Spot® 3000K IES File - Very Narrow 10°
Image Spot® 3000K IES File – Narrow 19°
Image Spot® 3000K IES File – Medium 25°
Image Spot® 3000K IES File – Wide 30°
Image Spot® 3000K LDT File - Very Narrow 10°
Image Spot® 3000K LDT File - Narrow 19°
Image Spot® 3000K LDT File - Medium 25°
Image Spot® 3000K LDT File - Wide 30°
Image Spot® 5500K IES File - Very Narrow 10°
Image Spot® 5500K IES File – Narrow 19°
Image Spot® 5500K IES File – Medium 25°
Image Spot® 5500K IES File – Wide 30°
Image Spot® 5500K LDT File - Very Narrow 10°
Image Spot® 5500K LDT File - Narrow 19°
Image Spot® 5500K LDT File - Medium 25°
Image Spot® 5500K LDT File - Wide 30°
Image Spot DMX Addressing Software Download
Photometric data for both the 3000K and 5500K Image Spot LED gobo projectors. A matching IES data file link can be found underneath each photometric chart.
Image Spot 3000K LDT File - Very Narrow 10º
Image Spot 3000K IES File - Narrow 19º
Image Spot 3000K IES File - Medium 25º
Image Spot 3000K IES File - Wide 30º
Image Spot 5500K LDT File - Very Narrow 10º
Image Spot 5500K IES File - Narrow 19º
Image Spot 5500K IES File - Medium 25º
Please complete this form
The different Image Spot Lens Optics provide a range of long to short projection capabilities with varying image diameters. Each Image Spot Lens Optic is designed to receive the optional Image Spot Lens Cover that prohibits water & debris from entering the front of the optic. This easy-to-access filter chamber is also useful for installing one of the diffusion filters found in the optional OPTI-FLECS Filter Pack.
Specifications:
Available colors: Black, Silver
Available beam angles: 10°, 19°, 25°, 30°
The Very Narrow - 10° Lens enables the longest projection capability.
Image Diameter = 3.8’ (1.15m) @ 20’ (6m) distance.
The Narrow - 19° Lens enables long projection capability with broader image.
Image Diameter = 6.6’ (2m) @ 20’ (6m) distance.
The Medium - 25° Lens supports mid-range projections.
Image Diameter = 7.9’ (2.4m) @ 20’ (6m) distance.
The Wide - 30° Lens produces the widest beam spread, making it the best for short throws.
Image Diameter = 8.2’ (2.5m) @ 20’ (6m) distance.
Product Numbers:
Contains three, 43mm OPTI-FLECS diffusion filters designed for the Image Spot to create varying levels of beam control for spot lighting applications. The kit also includes a retaining ring for quick & easy installation of the filter inside the Image Spot Lens Optic.
The OPTI-FLECS Filter Pack includes:
• Retaining Ring
• Soft Diffusion (R132) – 43mm dia.
• Smoothing Frost (R9101) – 43mm dia.
• Double Powder Frost (R3000) – 43mm dia.
3’ (1m) safety cable with convenient threaded connector designed to wrap around the fixture’s mounting point to provide security for any Image Spot installation.
The Rosco Pole Mount is a rugged mounting accessory for attaching Rosco Projectors and Rosco Cube products to interior or exterior round poles.
Powder-Coated Steel support that provides rigid attachment and a clean, mounted installation.
1-3/5” (42mm) open tubing provides room for power/data cables for a clean installation.
Pole Mounts attach to any round structure via Stainless Steel Straps (kit sold separately).
Product Numbers:
The Rosco Wall Mount allows for mounting Rosco Projectors and Rosco Cubes to interior or exterior vertical surfaces.
Powder-Coated Steel support that provides rigid attachment and a clean, mounted installation.
1-3/5” (42mm) open tubing provides room for power/data cables for a clean installation.
Product Numbers:
The Rosco Surface Mount allows for mounting Rosco Projectors and Rosco Cubes to interior or exterior horizontal surfaces.
Powder-Coated Steel support that provides rigid attachment and a clean, mounted installation.
1-3/5” (42mm) open tubing provides room for power/data cables for a clean installation.
Product Numbers:
